New HDF35 Hinged Frame, Flexible Cutterbar Draper

Specifications

Compare >>> Select up to 2 models to compare specifications

John DeereHDF35 Hinged Frame, Flexible Cutterbar Draper

Add Model --Please Select-- HD40F (Model year 2025) HD45F (Model year 2025) HD50F (Model year 2025)

Add Model --Please Select-- HD40F (Model year 2025) HD45F (Model year 2025) HD50F (Model year 2025)

Cutterbar length	10.7 m 35 ft
Knife drive	Double-cut, dual-drive, shaft-driven cutterbar: 10.2 cm 4 in.
Knife speed	X Series Combine: 520 cycles/min S-Series Combine: 490 cycles/min
Pickup reel operating speeds	8-70 rpm
Draper belts speed control	Hydraulic from cab (side belts only)

Type	Hinged frame flexible cutterbar

Type	Straight-line knife drive system
Length	10.7 m 35 ft
Knife drive	Double-cut, dual-drive, shaft-driven cutterbar: 10.2 cm 4 in.
Knife speed	X Series Combine: 520 cycles/min S-Series Combine: 490 cycles/min
Cutterbar tilt
Base skid shoe height	3.8 cm 1.5 in.

General
Number of slats	Base: six bat poly Optional: steel tine
Fingers	Base: nylon Optional: steel
Diameter	106.7 cm 42 in.
Height control	Hydraulic
Speed control	Hydraulic
Reel lift	Off the cutterbar: 100.6 cm 39.6 in.
Reel fore and aft	Fore of the cutterbar: 26.4 cm 10.4 in.
Fore of the cutterbar
Reel resume	Base
Reel reverse	Base
Operating speeds	8-70 rpm
Operating speeds (54-in. reel)

Number of slats
Diameter
Height control
Speed control
Operating speeds

Width	Side belts: 4.4 m 14.3 ft Center belts: 200 cm 79 in.
Belt depth	100 cm 39.8 in.
Cleat height	Cross belt cleat height: 19 mm 0.75 in.
Operating speed
Speed control	Hydraulic from cab (side belts only)
Center belt reverse	Base

Diameter	40.6 cm 16 in.
Feed drum fingers	Heavy-duty and round with breakaway notch and retainer Diameter: 16 mm 0.625 in.
Number of fingers	18
Auger finger platform	Triple chevron, retracting
Finger reach	152 mm 6 in.
Drum/auger reverse	Base
Operating speed	Low speed: 200 rpm High speed: 240 rpm
Center cleanout door	Base

Type	Electrohydraulic
Header height sensing on the ground	Base
Header height sensing off the ground	Base

Type	Optional: hydraulic drive 250-350 rpm
Fingered augers	Optional
Size	Diameter: 43.2 cm 17 in.

Platform length	11.5 m 37.8 ft
Overall operating depth	With dividers: 3.2 m 10.6 ft
Transport width, field position
Transport width on wheel, less dividers
Transport length, hitch extended

Date collected	24 Mar 2021
